Corally finely released its new front end for the Corally SP12X that is based on the ASSO/CRC front end. Corally has always had it own type front but after they won the World Championship using a CRC front end it could not take before the would release there own production of the ASSO front end.



New Corally Asso Style Front
Lower A arms

Here is the list of parts with there order number:

Part#   Item:

75950 12X WC Front suspension conversion kit
75960 12X WC Upper suspension mounts – 0°, 5° & 10° Caster (3 pairs)
75962 12X WC Upper suspension arms (1 pair)
75964 12X WC Lower A arms (1 pair)
75966 12X WC Upper turnbuckles (1 pair)
75968 12X WC Upper pivot sockets (1 pair)
75970 12X WC Pivot balls
75972 12X WC Steering blocks (1 pair)
75974 12X WC Kingpins (1 pair)
75976 12X WC Kingpin shims (8 pcs)
75978 12X WC Hingepins – Titanium (1 pair)
75979 12X WC Hingepins – Hardened steel (1 pair)
75980 12X WC Hingepins – Hardened steel – L shaped (1 pair)
75982 12X WC E-clips 1/8" (6 pcs)
75984 12X WC Setscrews 5-40 x 1/8" (4 pcs)
75986 12X WC Springs ,020 (1 pair)
75995 12X WC Bodyposts – Including body pivots and clips (4 pcs)

Source: Corally Web Site

 Here are some images:



New Corally Asso Style Front
Front ,020 Springs

New Corally Asso Style Front
Bodyposts – Including body pivots and clips

New Corally Asso Style Front
Upper suspension mounts – 0°, 5° & 10° Caster

New Corally Asso Style Front
E-clips 1/8
